File information:
File name:KD-G300.part1.rar
Size:2041 kB
Extension:
Mfg:JVC
Model:KD-G300 🔎 KDG300
Original:KD-G300 🔎
Descr:Service manual, schematic, user and parts list for CD RECEIVER (mp3) models: KD-G300 , KD-AR300
Group:Electronics > Automobile > Car Audio
Uploaded:11-07-2005
User:dupator
Multipart: 0  1  2

Information about the files in archive:
Decompress result:OK
Extracted files:1
File name KD-G300.pdf

SERVICE MANUAL CD RECEIVER 1 2004 MA036 KD-G300, KD-AR300 KD-AR300 S KD-G300 S Area Suffix J ----- Northern America TABLE OF CONTENTS 1 2 3 4 5 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-24 TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25 COPYRIGHT © 2004 VICTOR COMPANY OF JAPAN, LIMITED No.MA036 2004/1 SPECIFICATION AUDIO AMPLIFIER SECTION Maximum Power Output Front Rear Continuous Power Output Front (RMS) Rear Load Impedance Tone Control Range Frequency Response Signal-to-Noise Ratio Line-Out Level/Impedance Output Impedance Frequency Range [FM Tuner] FM AM Usable Sensitivity 50 dB Quieting Sensitivity Frequency Response Stereo Separation Capture Ratio [AM Tuner] Sensitivity Selectivity Type Signal Detection System Number of channels Frequency Response Dynamic Range Signal-to-Noise Ratio Wow and Flutter MP3 decoding format Bass Treble 50 W per channel 50 W per channel 19 W per channel into 4 , 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion. 19 W per channel into 4 , 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion. 4 (4 to 8 allowance) ±10 dB at 100 Hz ±10 dB at 10 kHz 40 Hz to 20 000 Hz 70 dB 2.5 V/20 k load (full scale) 1 k TUNER SECTION 87.5 MHz to 107.9 MHz 530 kHz to 1 710 kHz 11.3 dBf (1.0 µV/75 ) 16.3 dBf (1.8 µV/75 ) 40 Hz to 15 000 Hz 35 dB 1.5 dB 20 µV 35 dB CD PLAYER SECTION Compact disc player Non-contact optical pickup (semiconductor laser) 2 channels (stereo) 5 Hz to 20 000 Hz 96 dB 98 dB Less than measurable limit MPEG1/2 Audio Layer 3 Max. Bit Rate: 320 Kbps GENERAL Power Requirement Grounding System Allowable Operating Temperature Dimensions (W × H × D) Mass (approx.) Design and specifications are subject to change without notice. Installation Size (approx.) Panel Size (approx.) Operating Voltage DC 14.4 V (11 V to 16 V allowance) Negative ground 0ºC to +40ºC (32ºF to 104ºF) 182 mm × 52 mm × 150 mm (7-3/16" × 2-1/16" × 5-15/16") 188 mm × 58 mm × 11 mm (7-7/16" × 2-5/16" × 7/16") 1.4 kg (3.1 lbs) (excluding accessories) Alternate Channel Selectivity (400 kHz) 65 dB 1-2 (No.MA036) SECTION 1 PRECAUTION 1.1 Safety Precautions ! Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. ! Please use enough caution n
